Injection molding quality control determines whether your custom plastic parts meet specifications, function correctly in assembly, and satisfy regulatory requirements. This guide covers the complete QC process from first article inspection to production lot approval, including defect identification, measurement methods, and documentation standards.
Why Injection Molding Quality Control Matters
A single defective mold can produce thousands of non-conforming parts before the problem is detected. Without systematic quality control, defects propagate through your supply chain, causing assembly failures, field returns, and warranty claims. Effective QC catches issues at three stages:
- Pre-production: First Article Inspection (FAI) validates that the mold and process produce conforming parts
- In-process: Periodic sampling during production detects drift before large quantities are affected
- Pre-shipment: Final lot inspection confirms conformance before parts leave the factory
For sourcing context, see our China custom injection molding OEM buying guide.
First Article Inspection (FAI)
FAI is the most critical QC checkpoint. It verifies that the mold, material, and process parameters produce parts matching your drawings and specifications. A complete FAI includes:
Dimensional Inspection
Measure every critical dimension on the part drawing, typically 15-50 features depending on complexity. Use calibrated equipment appropriate to the tolerance:
| Tolerance Range | Measurement Tool | Typical Application |
|---|---|---|
| +/- 0.01mm or tighter | CMM (Coordinate Measuring Machine) | Precision medical, electronic parts |
| +/- 0.05mm | Digital calipers, micrometers | General mechanical parts |
| +/- 0.1mm | Digital calipers | Housings, covers, brackets |
| +/- 0.5mm or looser | Steel ruler, go/no-go gauges | Consumer goods, containers |
Document each measurement with actual vs nominal values and deviation. Any dimension outside tolerance requires corrective action before production approval.
Visual Inspection Standards
Visual defects affect aesthetics, structural integrity, and customer perception. Inspect parts under standardized lighting (1000-1500 lux) against a neutral background. Common defect categories:
| Defect Type | Description | Acceptance Criteria (Typical) |
|---|---|---|
| Flash | Excess material at parting line | None visible on critical surfaces; max 0.2mm on non-critical |
| Short shot | Incomplete fill of mold cavity | None permitted |
| Sink marks | Surface depression at thick sections | Not detectable by touch; max 0.1mm depth |
| Weld lines | Visible line where melt fronts meet | Acceptable if not on critical surface |
| Warping | Dimensional distortion after cooling | Within flatness tolerance on drawing |
| Burn marks | Discoloration from trapped gas | None on visible surfaces |
| Silver streaks | Splay from moisture in material | None on Class A surfaces |
Material Testing and Verification
Confirming that the correct material was used is essential for parts requiring specific mechanical, thermal, or regulatory properties.
Material Identification Tests
- Density test — Measure specific gravity (ASTM D792); compare against material datasheet
- Melt Flow Index (MFI) — Verify melt flow rate matches specified grade (ASTM D1238)
- DSC (Differential Scanning Calorimetry) — Identifies polymer type and crystallinity
- FTIR spectroscopy — Confirms polymer chemistry; detects contamination
- Burn test — Quick field identification by flame color, smoke, and odor (preliminary only)
Mechanical Property Testing
| Test | Standard | What It Measures |
|---|---|---|
| Tensile strength | ASTM D638 | Maximum stress before failure |
| Flexural strength | ASTM D790 | Bending strength and modulus |
| Izod impact | ASTM D256 | Resistance to impact fracture |
| Hardness | ASTM D785 (Rockwell) | Surface indentation resistance |
In-Process Quality Control During Production
Once FAI is approved, in-process QC monitors production stability. Define a sampling plan based on AQL (Acceptance Quality Limit) standards:
AQL Sampling Plan (ISO 2859-1)
| Lot Size | Sample Size | Accept (Critical) | Accept (Major) | Accept (Minor) |
|---|---|---|---|---|
| 501-1200 | 80 | 0 | 2 | 5 |
| 1201-3200 | 125 | 1 | 3 | 7 |
| 3201-10000 | 200 | 1 | 5 | 10 |
| 10001-35000 | 315 | 2 | 7 | 14 |
Critical defects (safety, regulatory) typically use AQL 0.25; Major defects (functional) use AQL 1.0; Minor defects (cosmetic) use AQL 2.5 or 4.0.
Process Parameter Monitoring
Injection molding quality depends on stable process parameters. Key variables to monitor and log:
- Melt temperature — Measured at nozzle; deviation indicates heater or sensor issue
- Mold temperature — Measured at cavity surface; affects cooling rate and shrinkage
- Injection pressure — Peak and hold pressure; drift indicates wear or material variation
- Cycle time — Total cycle; sudden changes indicate mechanical issues
- Cushion distance — Remaining screw travel after injection; consistency confirms shot stability
Common Defects and Root Causes
| Defect | Primary Cause | Corrective Action |
|---|---|---|
| Short shot | Insufficient injection pressure or material shortage | Increase pressure; check feed; raise melt temperature |
| Flash | Excessive clamp force or worn mold | Reduce injection pressure; inspect mold parting line |
| Sink marks | Thick sections cooling unevenly | Reduce wall thickness; increase hold pressure; extend cooling time |
| Warping | Differential shrinkage across part | Adjust mold temperature; modify gate location; add ribs |
| Burn marks | Trapped air or gas in cavity | Add vents; reduce injection speed; check venting |
PPAP and Production Documentation
For automotive, medical, and aerospace customers, Production Part Approval Process (PPAP) documentation is mandatory. Core elements include:
- Design Record — Approved drawings and specifications
- Process Flow Diagram — Step-by-step manufacturing sequence
- Control Plan — QC checkpoints, methods, frequency, and responsibility
- MSA (Measurement System Analysis) — Gauge R&R study confirming measurement repeatability
- Capability Study — CpK and PpK indices showing process capability (target CpK 1.33+)
